| Place of Origin: | China |
|---|---|
| Brand Name: | CoatTech |
| Certification: | CE |
| Model Number: | CT-4009 |
| Minimum Order Quantity: | 1 |
| Price: | USD5200-USD10000/SET |
| Packaging Details: | With regular Film and Carton |
| Delivery Time: | 15 DAYS After Deposit |
| Payment Terms: | T/T, MoneyGram, Western Union, D/A |
| Supply Ability: | 50SET/MONTH |
| NAME: | CT-4009 | Power Supply: | 380V/50HZ/3Ph Or Other Option |
|---|---|---|---|
| Using Energy: | Gas /Diesel/ IR | Main Door: | Fold Style |
| Motor: | Chinese Brand Or Import Brand | Control Sytem: | Switch Style Or PLC Touch Screen Control |
| Wall: | Metal Sheld,EPS,Rock Wool Of PU For Option | Color: | White Or Other Option |
| Application: | Car Painting | Energy Sources: | GAS/Eletric/Diesel |
| Coating: | 10-50um | Dimention: | 7000 X 5350 X 3400 Mm |
| Highlight: | spray booth fresh air unit,make-up unit for spray booths,spray booth heating generator |
||
Overview Maintain perfect spraying conditions regardless of the weather outside. The CoatTech Air Supply Unit (ASU/AMU) captures raw outdoor air, filters it to remove contaminants, and heats it to your precise application temperature. This unit is essential for creating positive pressure inside the booth, which pushes dust out of cracks and ensures a clean, debris-free finish.
Core Features
Instant Direct Heating: Utilizes a direct-fired gas burner system (98% thermal efficiency) placed directly in the airstream for immediate temperature control during cold winters.
Intelligent Pressure Balance: Automatic damper actuators and VFDs modulate airflow to maintain a slight positive pressure (+5 Pa) inside the cabin.
Clean Room Standards: A multi-barrier filtration bank (G4 + F7) ensures that all air entering the paint shop is free of pollen, dust, and insects.
Season Switch: Summer/Winter bypass mode allows you to circulate fresh air without heating during warmer months to save fuel.
Technical Specification Sheet
| Parameter | Series BB: Roof-Top Vertical | Series CC: Side-Draft Horizontal | Series DD: Industrial Plant Supply |
| Catalog Code | CT-HVAC-V | CT-HVAC-H | CT-HVAC-IND |
| Air Delivery | 18,000 m3/h | 35,000 m3/h | 60,000 m3/h + |
| Thermal Output | 200 kW (172,000 kcal) | 400 kW (344,000 kcal) | 1000 kW+ (Custom) |
| Burner Type | Riello Gas / Diesel | Eclipse / Midco Direct Gas | Steam Coil / Hot Water |
| Fan Motor | 5.5 kW Belt Drive | 11 kW - 15 kW Belt Drive | 30 kW - 55 kW Direct Drive |
| Temp Rise | 25°C Delta-T | 40°C Delta-T | Custom Specification |
| Control Logic | Thermostat + Damper | PID PLC + Pressure Sensor | Full BMS Integration |
| Cabinet Skin | Single Wall Galvanized | 50mm Rockwool Insulated | Double Skin Weatherproof |
| Fuel Source | LPG / Natural Gas | LPG / Natural Gas | Natural Gas / Steam |
![]()
