Automatic Roller Coating Line – Precision, Speed & Low Waste for Flat Substrates

MOQ: 1
Price: USD5000/SET-USD50000/SET
Standard Packaging: With regular Film and Carton
Delivery Period: 15 DAYS After Deposit
Payment Method: T/T
Supply Capacity: 15SET/MONTH
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
CoatTech
Certification
CE
Model Number
Roller-17
Coating Thickness:
0.1-3mm
Power Supply:
AC 380V/50Hz
Heating Method:
Electric Heating
Condition:
New
Coating Speed:
Adjustable
Total Power:
10-50KW
Safety Features:
Emergency Stop Button
Coating Width:
500-2000mm
Control System:
PLC
Drying Temperature:
50-200℃
Coating Method:
Continuous
Frequency Converter:
Schneider 、Mitsubishi 、Delta
Conveyor Type:
Roller Conveyor
Dimention:
As Require
Main Door:
Fold Style Or Electric Rolling Style
Material:
Steel
Dryingmethod:
Hot Air Or Infrared Drying
Coatingspeed:
0-50 M/min
Energy Sources:
Water, Electricity,gas
Voltage:
380v Three Phase 50-60HZ
Productname:
Roller Coating Line
Safetyfeatures:
Emergency Stop, Safety Guards, Overload Protection
Product Description

1.Automatic Roller Coating Line – Precision, Speed & Low Waste for Flat Substrates


2.Short Intro


CoatTech's roller coating lines deliver uniform, high-quality finishes on flat or slightly curved surfaces with minimal paint overspray. Ideal for high-volume production of metal panels, doors, furniture components, and automotive parts – with PLC control and easy integration into your existing workflow.


3.Key Features


Precision Coating Control: Servo-driven rollers with adjustable pressure and speed ensure consistent film thickness (±2μm) across wide substrates.


High Efficiency & Low Waste: Direct roller transfer achieves >90% paint utilization, significantly reducing material cost vs. spray methods.


Smart PLC Operation: User-friendly HMI interface with recipe storage, fault diagnostics, and optional IoT connectivity for production tracking.


Flexible Configuration: Single-color or multi-color lines; compatible with solvent-based, water-based, or UV-curable coatings.


Turnkey Ready: Includes pre-treatment, coating, leveling, and curing sections – fully tested before shipment for fast on-site commissioning.


4.Technical Specification


Parameter Specification
Max. Workpiece Size Width: up to 1,300mm; Length: customizable; Thickness: 3–50mm
Coating Speed 5–30 m/min (stepless adjustment)
Film Thickness 10–120 μm (adjustable via roller gap & viscosity)
Roller Material Chrome-plated steel / rubber / polyurethane (application-specific)
Drive System Servo motor + precision gearbox for stable speed control
Control System PLC + 10" HMI touch panel; optional remote monitoring
Power Requirement 380V / 50Hz, ~15–30 kW (depends on configuration)
Curing Option Compatible with IR, hot air, or UV curing modules


5.Applications

Perfect for coating:
Metal: Aluminum composite panels, steel doors, appliance housings, automotive trim
Wood: Furniture panels, flooring, decorative laminates
Composite: PVC, WPC, fiber cement boards
Other: Glass, acrylic sheets, and flat industrial components

Customization & Options
Line length and station layout adapted to your factory floor
Optional modules: Automatic edge sealing, dust removal, viscosity control system, robotic loading/unloading
Coating compatibility: We configure rollers and pumps for your specific paint type (PU, PE, AC, UV, water-based)

6.FAQ
Q: Can the roller coating line handle different workpiece sizes in one production run?
A: Yes. With quick-adjust roller gaps and servo-controlled conveyors, changeovers between sizes can be completed in under 15 minutes. We also offer auto-recognition options for mixed-batch production.
Q: How do you ensure coating uniformity on long panels?
A: Our lines feature precision-guided roller alignment, real-time thickness monitoring (optional), and stable conveyor tension control to prevent edge buildup or center thinning.
Q: Do you provide training and technical support?
A: Yes. We offer on-site or remote operator training, detailed manuals in English, and lifetime technical consultation. Spare parts are stocked for fast global delivery.

Automatic Roller Coating Line – Precision, Speed & Low Waste for Flat Substrates 0

6.Strong CTA
Ready to boost your coating efficiency with minimal waste? Contact CoatTech today for a FREE process evaluation & customized roller line proposal!

Automatic Roller Coating Line – Precision, Speed & Low Waste for Flat Substrates 1
