| Cabin System |
|
| Wall Panel and Roof |
EPS colorful steel skin panel, 50mm thick, steel 0.426mm thick, tongue & groove style, compound construction, anti-flame and heat-insulation, galvanized steel roof panel |
| Entry Door |
Folding metal sheet door, 3 pcs, size: 3000(W) * 2700(H) mm, rectangle window tempered glass, 5mm thick |
| Personnel Door |
Size: 700(W) * 2000(H) mm, alloy aluminum door, 1 set, rectangle window tempered glass, 5mm thick, with pressure lock |
| Basement |
Made by high-quality galvanized 1.2mm steel sheet and square tubes assembling, 300mm height; 2 rows of grilles (305mm) made by flat bar and round steel, 304mm; 3 rows of embossed plates, Galvanized; 2 rows of slopes, 1 set of foot platform |
| Air Circulation System |
|
| Intake Fan |
2 sets of YDW-4kW double-intake centrifugal fan, air capacity 26000 m³/h in total (Low noise) |
| Exhaust Fan |
1 set of YDW-5.5kW exhaust fan, air capacity 15500 m³/h in total (Low noise) |
| Fan Cabinet |
Made by painted sections and powder-coated steel plate; the exhaust duct made by high-quality galvanized steel, and professional flange |
| Air Exhausted Pipe |
1.5 meter length, 1 set of 90-degree elbow, can be adjusted by customers |
| Roof System |
|
| Beam |
Made by 4040 galvanized square pipe, with supporting; and also 4040mm angle iron, connected by screw |
| Plenum |
Made by 0.8mm galvanized steel, powder-coated on the surface. The roof filter support frame made by 2525 and 1515 galvanized square tubes, powder-coated on the surface |
| Secondary Frame |
Made of 1.2mm thick galvanized sheet compression molding, spraying treatment, riveting pull; Filter support is made of 2525mm and 1515mm galvanized square tube welding molding, spraying treatment |
| Heating System (Diesel) |
|
| Burner |
1 set of Italy Riello G10 diesel burner, the heat capacity is 95-213 kW (80,000 - 190,000 kcal/h) |
| Heat Exchanger |
Made by high-quality Stainless steel, argon arc welding |
| Pneumatic Damper |
1 set of Pneumatic-damper for changing spraying and baking automatically |
| Oil Box |
1 set |
| Smoke Exhausted Pipe |
1 meter length and 1 piece of cap |
| Parameter |
Highest temperature: 80℃; Temperature rising time: 18-30 minutes (20℃-80℃) |
| Purification System |
|
| Intake Filter |
High quality imported filter, captures particles larger than 10μm (15mm thickness); Purpose: Filter larger dust in the air |
| Roof Filter |
High efficiency imported Italy filters, captures particles larger than 4μm (22mm thickness); Purpose: The most important filter cotton, filters smaller dust and spreads air uniformly |
| Floor Filter |
Fiberglass filter, TSP≤14mg/m³; Purpose: Filter redundant paint in the air |
| Lights |
|
| Roof Lights |
1. 8 units * 3 pcs = 24 pcs * 21W, LED with electronic ballasts, powder-coated light box; 2. Using lighting tube and electronic ballasts, lampshade with mirror stainless steel reflection, 45° angle installation, effectively ensures no ghosting and operating blind spot; 3. Light box with 0.45mm color steel plate and aluminum frame, equipped with glass cover |
| Side Lights |
6 units * 2 pcs = 12 pcs * 21W, LED, with electronic ballasts, vertically set, powder-coated light box |
| Control System |
Export type. Microcomputer controlling system, programs all functions in each phase of every cycle work. Includes adjusting parameters of time, main circuit multi-protection, controls for light, time, spraying, failure indicator, and emergency stop. Reasonable structure and stable performance |
