Automatic UV Roller Coating & Curing Production Line High-Speed Precision Finishing System for Flat Panels

MOQ: 1
Price: USD2000-USD10000/SET
Standard Packaging: With regular Film and Carton
Delivery Period: 15 DAYS After Deposit
Payment Method: T/T
Supply Capacity: 500SET/MONTH
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
CoatTech
Certification
CE
Model Number
OCCL-23
Warranty:
1 Year
Control System:
PLC
Material:
Steel
Conveyor Load Capacity:
Up To 500kg
Conveyor Speed:
Adjustable
Coating Color:
Customizable
Heating Method:
Electric/ Gas/ Infrared
Power Supply:
AC 380V/50Hz
Type:
Continuous Coating Line
Conveyor Type:
Overhead Conveyor
Cooling Method:
Air/ Water
Heating Temperature:
Adjustable
Cooling Time:
Adjustable
Coating Type:
Powder Coating
Highlight:

Automatic UV roller coating line

,

High-speed panel curing system

,

Precision flat panel finishing

Product Description

Technical Overview: This fully automated line is engineered for the rapid, high-quality finishing of flat substrates. It replaces manual spraying with precision reverse-roller coating technology, achieving near 100% material utilization (zero waste). The integrated high-intensity UV curing tunnel ensures instant drying, allowing products to be packed immediately off the line.

The Integrated Process & Features:

  1. Surface Preparation (Dust Cleaning):

    • Double-roller nylon brush machine with strong air knives removes all sawdust and contaminants from substrate pores to ensure a defect-free finish.

  2. Precision Roller Coater (Single/Double Head):

    • Metering System: Utilizes a separate "Doctor Roller" (steel) and "Application Roller" (rubber) with precise gap adjustment to control coating thickness down to micron levels (typically 10g–30g/m²).

    • Material Efficiency: Coating material is continuously circulated; unused material is returned to the tank, eliminating waste.

  3. UV Curing Tunnel:

    • Lamp Technology: Equipped with high-power Mercury Vapor or Gallium doped UV lamps (80W/cm – 120W/cm). Gallium lamps are used for deeper curing of pigmented coatings.

    • Temperature Control: Integrated cooling fans and optimized reflectors prevent heat buildup, allowing curing of heat-sensitive substrates like PVC or thin wood veneers.

Technical Specifications Table (Standard 1300mm Width Line):



Parameter Specification Details
Max Working Width 1300 mm (Other widths: 600mm, 1950mm)
Working Thickness 2mm – 80mm (Automatic Thickness Adjustment)
Min Working Length 300 mm
Process Speed 5 – 20 m/min (Adjustable via VFD)
Roller Coater Type Reverse Roller Coating (Single or Double Head options)
Application Roller Laser Engraved EPDM/PU Rubber (Shore hardness optional)
UV Lamp Power 2 – 3 Lamps × 9KW (Mercury/Gallium options)
Total Installed Power Approx. 35 KW (depending on configuration)
Control Interface PLC Touch Screen + Button Controls

Automatic UV Roller Coating & Curing Production Line High-Speed Precision Finishing System for Flat Panels 0Automatic UV Roller Coating & Curing Production Line High-Speed Precision Finishing System for Flat Panels 1

Automatic UV Roller Coating & Curing Production Line High-Speed Precision Finishing System for Flat Panels 2
