| Place of Origin: | China |
|---|---|
| Brand Name: | CoatTech |
| Certification: | CE |
| Model Number: | CT-4006 |
| Minimum Order Quantity: | 1 |
| Price: | USD5200-USD10000/SET |
| Packaging Details: | With regular Film and Carton |
| Delivery Time: | 15 DAYS After Deposit |
| Payment Terms: | T/T, MoneyGram, Western Union, D/A |
| Supply Ability: | 50SET/MONTH |
| NAME: | CT-HT-4006 | Power Supply: | 380V/50HZ/3Ph Or Other Option |
|---|---|---|---|
| Using Energy: | Gas /Diesel/ IR | Main Door: | Fold Style |
| Motor: | Chinese Brand Or Import Brand | Control Sytem: | Switch Style Or PLC Touch Screen Control |
| Wall: | Metal Sheld,EPS,Rock Wool Of PU For Option | Color: | White Or Other Option |
| Application: | Car Painting | Energy Sources: | GAS/Eletric/Diesel |
| Coating: | 10-50um | Dimention: | 7000 X 5350 X 3400 Mm |
| Highlight: | Industrial air make-up unit for spray booths,HVAC handling unit spray booth,AMU spray booth HVAC system |
||
Overview In cold climates or high-precision paint shops, drawing raw air from outside can ruin a paint job. The CoatTech Air Make-Up Unit (AMU) filters, heats, and pressurizes incoming fresh air before it enters your spray booth. This ensures a consistent spraying temperature year-round and maintains positive pressure to keep dust out.
Core Features
Direct Fired Heating: 98% thermal efficiency gas burners heat the air instantly as it passes through the flame, providing massive heating capacity for winter months.
Positive Pressure Control: Variable Frequency Drives (VFD) automatically adjust fan speed to maintain correct cabin pressure.
Multi-Stage Filtration: Includes bag filters and panel filters to ensure air is 99% dust-free before entering the workspace.
Integration: Can be retrofitted to existing spray booths or installed as a standalone plant ventilation system.
Technical Specification Sheet
| Parameter | Series BB: Vertical (Roof Mount) | Series CC: Horizontal (Side) | Series DD: High-Capacity Plant |
| Catalog Code | CT-AMU-V | CT-AMU-H | CT-AMU-PLANT |
| Air Volume | 10,000 - 25,000 m3/h | 20,000 - 40,000 m3/h | 50,000 - 100,000 m3/h |
| Heating Capacity | 200,000 kCal/h | 400,000 kCal/h | 1,000,000 kCal/h + |
| Burner Type | Direct Fired Gas (LPG/NG) | Direct Fired or Diesel Exch. | Steam / Hot Water Coil |
| Temp Rise | 25°C - 40°C Rise | 30°C - 60°C Rise | Custom Specification |
| Motor Power | 5.5 kW - 11 kW | 11 kW - 22 kW | 30 kW - 75 kW |
| Damper Control | Belimo Electric Actuator | Belimo Electric Actuator | Pneumatic Modulation |
| Housing | Galvanized / Powder Coated | 50mm Insulated Skin | Double Skin Weatherproof |
| Filter Grade | G4 Panel + F7 Bag | G4 + F7 + F9 (Optional) | HEPA (Optional) |
![]()
