Overhead Conveyor Chain Components, Tracks & Drive Units (QXG & XT Series)

Basic Information
Place of Origin: China
Brand Name: CoatTech
Certification: CE
Model Number: OCCL-35
Minimum Order Quantity: 1
Price: USD2000-USD10000/SET
Packaging Details: With regular Film and Carton
Delivery Time: 15 DAYS After Deposit
Payment Terms: T/T
Supply Ability: 500SET/MONTH
Warranty: 1 Year Control System: PLC
Material: Steel Conveyor Load Capacity: Up To 500kg
Conveyor Speed: Adjustable Coating Color: Customizable
Heating Method: Electric/ Gas/ Infrared Power Supply: AC 380V/50Hz
Type: Continuous Coating Line Conveyor Type: Overhead Conveyor
Cooling Method: Air/ Water Heating Temperature: Adjustable
Cooling Time: Adjustable Coating Type: Powder Coating
Highlight:

Overhead Conveyor Chain Tracks

,

QXG Series Conveyor Drive Units

,

XT Series Conveyor Components

Overhead Conveyor Chain Components, Tracks & Drive Units (QXG & XT Series)

Overview Keep your production line moving with CoatTech’s premium conveyor components. We supply complete chain systems as well as individual spare parts for maintenance. From the versatile QXG Enclosed Track series to the heavy-duty American Standard XT Forged Chain, our components are heat-treated for high tensile strength and wear resistance.

Core Features

Technical Specification Sheet

Parameter Series V: QXG Enclosed (Light) Series W: 5-Ton Enclosed (Medium) Series X: XT-348/458 (Heavy)
Catalog Code QXG-150 / 200 QXG-250 / 300 XT-348 / XT-458 / XT-678
Chain Pitch 150mm / 200mm 250mm / 300mm 3" (76.2mm) / 4" (101.6mm)
Single Load 30 kg / Hanger 50 kg - 100 kg / Hanger 150 kg - 600 kg / Trolley
Tensile Strength 2000 kgf 4000 - 5000 kgf 10,000 - 20,000 kgf
Track Material C-Type Manganese Steel Heavy C-Type Steel I-Beam (10# / 12# Steel)
Curve Radius R600 / R800 / R1000 R1000 / R1200 R1500+ (Roller Turns)
Lubrication Automatic Oiler Cup Auto Mist Lubricator Auto Shot Lubricator
Drive Unit 1.5 kW - 2.2 kW 2.2 kW - 5.5 kW 5.5 kW - 11 kW

Applications:

Powder coating lines, assembly lines, slaughterhouse conveyors, garment handling systems, and electroplating lines.

Overhead Conveyor Chain Components, Tracks & Drive Units (QXG & XT Series) 0Overhead Conveyor Chain Components, Tracks & Drive Units (QXG & XT Series) 1Overhead Conveyor Chain Components, Tracks & Drive Units (QXG & XT Series) 2Overhead Conveyor Chain Components, Tracks & Drive Units (QXG & XT Series) 3

Water Filtration is an environmental protection equipment used for waste paint exhaust gas treatment. It is

mainly used for spray painting exhaust gas treatment in spray painting assembly line workshops in various

industries. It has the advantages of simple operation, stable use and safety.

FAQ
1,Who are we?
CoatTech Intelligent Equipment(Guangzhou) CO.,LTD is a professional enterprise that produces environmental
protection equipment.

2,How do we ensure quality?
Always conduct final inspection before shipment.

3,What can you buy from us?
The main product is spray booth,coating line,painting line.

4,Why do you want to purchase from us instead of other suppliers?
We have been specializing in the production of environmental protection equipment for many years, and are a manufacturer
of environmental protection equipment that integrates design, research and development, production, and after-sales service.

5,What services can we provide?
Accepted delivery methods: FOB, CFR, CIF, EXW, CIP; Accepted payment currencies: USD, EUR, AUD, RMB;
Accepted payment methods: wire transfer, letter of credit, cash.

6,What is your delivery date?
Normally, we will send you our standard specification goods within 10-15 days after receiving your payment.
This depends on the quantity you order.

7,Can you design the artwork(design) according to our requirements?
Of course we can. All products can be customized according to your own design.

8,Are you a factory or a trading company?
We are a factory with our own design and production, and competitive price advantages.

9,Where is your factory located?
Guangzhou City,Guangdong Province, China.

10. How do I get there?
About half an hour's drive from Guangzhou International Airport. Welcome friends from all over the world to our factory.


Overhead Conveyor Chain Components, Tracks & Drive Units (QXG & XT Series) 4
Overhead Conveyor Chain Components, Tracks & Drive Units (QXG & XT Series) 5Overhead Conveyor Chain Components, Tracks & Drive Units (QXG & XT Series) 6Overhead Conveyor Chain Components, Tracks & Drive Units (QXG & XT Series) 7
Overhead Conveyor Chain Components, Tracks & Drive Units (QXG & XT Series) 8
Overhead Conveyor Chain Components, Tracks & Drive Units (QXG & XT Series) 9
Overhead Conveyor Chain Components, Tracks & Drive Units (QXG & XT Series) 10
Overhead Conveyor Chain Components, Tracks & Drive Units (QXG & XT Series) 11
