Automatic Powder Feeding Center with Vibrating Hopper & Fluidized Bed

MOQ: 1
Price: USD1400-14000/SET
Standard Packaging: With regular Film and Carton
Delivery Period: 15 DAYS After Deposit
Payment Method: T/T
Supply Capacity: 100SET/MONTH
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
CoatTech
Certification
CE
Model Number
Auto-10
Name:
Smart Painting Line
Sub-Name:
Automatic Spray Line
Power Supply::
220V/50HZ Or Other Option
Motor::
Chinese Brand Or Import Brand
Control Sytem::
Switch Style Or PLC Touch Screen Control
Color::
White Or Other Option
Application::
Automobile Or Package Or Leather
Energy Sources::
Electricity
Coating:
10-50um
Dimention::
As Require
Highlight:

automatic powder feeding center with vibrating hopper

,

fluidized bed powder feeding system

,

smart painting line powder feeder

Product Description

Automatic Powder Feeding Center with Vibrating Hopper & Fluidized Bed




Overview The CoatTech Powder Feed Center is the "brain" of your automated coating line. It centralizes powder management, ensuring a steady, surge-free flow of powder to all spray guns. Designed for rapid color changes, the system automatically cleans the spray guns, powder pumps, and suction tubes with powerful blasts of compressed air at the push of a button.

Core Features

  • Superior Fluidization: The porous plate at the bottom of the hopper gently aerates the powder, making it behave like a liquid for smooth, consistent pumping.

  • Auto-Cleaning Cycle: Automatically purges the entire powder circuit (Venturi pumps, hoses, and guns) to prevent color contamination during changeovers.

  • Level Monitoring: Integrated ultrasonic sensors detect low powder levels and trigger an alarm or auto-refill from a virgin powder box.

  • Vibration Table: An angled vibration table helps empty the powder box completely, minimizing material waste.

Technical Specification Sheet



Parameter Series EE: Standard Hopper (Manual) Series FF: Auto-Feed (Reciprocator) Series GG: Fast-Color Management
Catalog Code CT-FEED-MAN CT-FEED-AUTO CT-FEED-MAGIC
Capacity 50 Liters / 100 lbs 100 Liters / 200 lbs 200 Liters + Box Feed
Pump Capacity Up to 8 Injectors Up to 16 Injectors Up to 24 Injectors
Cleaning Mode Manual Blow-off Semi-Auto Button Fully Automated PLC Sequence
Fluidization Bottom Plate Full Bed Fluidization Multi-Zone Aeration
Sieve System Optional Top Screen Integrated Vibratory Sieve Ultrasonic Rotary Sieve
Material Stainless Steel 304 Stainless Steel 304 Anti-Static Engineering Plastic
Voltage 220V / 1 Phase 220V / 1 Phase 380V / 3 Phase
Air Consumption 200 L/min 500 L/min 1000 L/min (Cleaning cycle)

Automatic Powder Feeding Center with Vibrating Hopper & Fluidized Bed 0
Automatic Powder Feeding Center with Vibrating Hopper & Fluidized Bed 1
Automatic Powder Feeding Center with Vibrating Hopper & Fluidized Bed 2
Automatic Powder Feeding Center with Vibrating Hopper & Fluidized Bed 3
Automatic Powder Feeding Center with Vibrating Hopper & Fluidized Bed 4

Automatic Powder Feeding Center with Vibrating Hopper & Fluidized Bed 5
Automatic Powder Feeding Center with Vibrating Hopper & Fluidized Bed 6


If you have any doubt or idea,please send the inquiry,we will respond to you immediately!
