CoatTech Custom Engineered Galvanized Paint Lines Tailor-Made Dimensions and Specs for Unique Industrial Needs

MOQ:	1
Price:	USD5200-USD10000/SET
Standard Packaging:	With regular Film and Carton
Delivery Period:	15 DAYS After Deposit
Payment Method:	T/T, MoneyGram, Western Union, D/A
Supply Capacity:	50SET/MONTH

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

CoatTech

Certification

Model Number

CT-USA-08

NAME:

CT-USA-08

Power Supply:

380V/50HZ/3Ph Or Other Option

Using Energy:

Gas /Diesel/ IR

Main Door:

Fold Style

Motor:

Chinese Brand Or Import Brand

Control Sytem:

Switch Style Or PLC Touch Screen Control

Wall:

Metal Sheld,EPS,Rock Wool Of PU For Option

Color:

White Or Other Option

Application:

Car Painting

Energy Sources:

GAS/Eletric/Diesel

Coating:

10-50um

Dimention:

7000 X 5350 X 3400 Mm

Highlight:

custom galvanized paint lines

engineered spray booth specs

industrial spray booth dimensions

Product Description

CoatTech Custom Engineered Galvanized Paint Lines Tailor-Made Dimensions and Specs for Unique Industrial Needs

Product Overview

At CoatTech, we don't just sell standard boxes. Based on our robust galvanized platform, we can customize dimensions, airflow (side draft/downdraft), and electrical standards (208V/480V 60Hz for USA). Whether you need a longer cabin for trucks or a wider one for aerospace parts, we build to your blueprint

Key Advantages

Flexible Sizing: Length, Width, and Height can be modified.
Global Power: Motors available for 50Hz or 60Hz grids.
Modular Assembly: Bolt-together galvanized panels for easy onsite assembly. Specs Highlight:
Standard Size: 5x6.5x3.95m (Reference)
Custom Option: Length up to 15m+, Height up to 6m
Structure: Heavy Duty 1.8mm Bent Steel

The CoatTech Difference: Workmanship & Quality

At CoatTech, we don't just assemble parts; we engineer solutions.

Precision Bending: Our wall panels aren't just cut; they are bent to form self-supporting structures. This interlocking design provides better airtight sealing than standard tongue-and-groove panels, preventing dust ingress.
Premium Components: We utilize branded components like Riello burners (Italy) and optional ABB/Siemens motors or UL-listed electrical components upon request for our American clients.
Customization: We understand every workshop is unique. From voltage (208V/240V/480V @ 60Hz) to dimensions, we build to your specific requirements.

Technical Specifications

Feature	Specification Details
Model No.	CoatTech-D171110 (Customizable)
Internal Dimensions	5000 (L) x 6500 (W) x 3950 (H) mm
External Dimensions	6150 (L) x 6650 (W) x 4705 (H) mm
Wall Structure	1.8mm Galvanized Steel (Bent Process) + 50mm Rock Wool (80kg/m³)
Main Door	5500 x 4000 mm (Electric Rolling Shutter / Heavy Duty)
Airflow Style	Semi-Downdraft / Rear Wall Extraction
Intake System	2 x 3KW Double-Intake Centrifugal Fans (20,000 m³/h)
Exhaust System	1 x 11KW High-Pressure Centrifugal Fan (40,000 m³/h)
Heating System	Riello RS5 Diesel Burner (180,000 kcal/h) + SUS304 Heat Exchanger
Drying Power	12 x Infrared Lamp Boxes (Total 30KW) for spot curing
Lighting	IP55 Explosion-proof LED Lighting (Angle + Vertical mount)
Filtration	G3 Pre-filter, F5 Ceiling Filter, Fiberglass Floor Filter, M-Shape Active Carbon
Control System	Relay Control with Overload Protection & Fault Indicator
Voltage/Frequency	Customizable (e.g., 208V/220V/480V, 60Hz for USA; 380V/415V, 50Hz for others)

FAQ
1,Who are we?
CoatTech Intelligent Equipment(Guangzhou) CO.,LTD is a professional enterprise that produces environmental
protection equipment.

2,How do we ensure quality?
Always conduct final inspection before shipment.

3,What can you buy from us?
The main product is spray booth,coating line,painting line.

4,Why do you want to purchase from us instead of other suppliers?
We have been specializing in the production of environmental protection equipment for many years, and are a manufacturer
of environmental protection equipment that integrates design, research and development, production, and after-sales service.

5,What services can we provide?
Accepted delivery methods: FOB, CFR, CIF, EXW, CIP; Accepted payment currencies: USD, EUR, AUD, RMB;
Accepted payment methods: wire transfer, letter of credit, cash.

6,What is your delivery date?
Normally, we will send you our standard specification goods within 10-15 days after receiving your payment.
This depends on the quantity you order.

7,Can you design the artwork(design) according to our requirements?
Of course we can. All products can be customized according to your own design.

8,Are you a factory or a trading company?
We are a factory with our own design and production, and competitive price advantages.

9,Where is your factory located?
Guangzhou City,Guangdong Province, China.

10. How do I get there?
About half an hour's drive from Guangzhou International Airport. Welcome friends from all over the world to our factory.
