Automated Overhead Paint Line | High-Volume Industrial Finishing System

MOQ:	1
Price:	USD2000-USD10000/SET
Standard Packaging:	With regular Film and Carton
Delivery Period:	15 DAYS After Deposit
Payment Method:	T/T
Supply Capacity:	500SET/MONTH

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

CoatTech

Certification

Model Number

OCCL-20

Warranty:

1 Year

Control System:

Material:

Steel

Conveyor Load Capacity:

Up To 500kg

Conveyor Speed:

Adjustable

Coating Color:

Customizable

Heating Method:

Electric/ Gas/ Infrared

Power Supply:

AC 380V/50Hz

Type:

Continuous Coating Line

Conveyor Type:

Overhead Conveyor

Cooling Method:

Air/ Water

Heating Temperature:

Adjustable

Cooling Time:

Adjustable

Coating Type:

Powder Coating

Product Description

Automated Overhead Paint Line | High-Volume Industrial Finishing System

Maximize production throughput with our fully automated overhead paint line. integrated conveyor system

for consistent powder or liquid coating. Request a custom proposal today!

Transition from manual batch processing to continuous, high-volume automated finishing with our turnkey Overhead Paint Line systems. Designed for industrial manufacturers requiring consistent quality and rapid throughput, this integrated solution utilizes unused ceiling space to transport parts seamlessly through every stage of the finishing process—from loading and multi-stage pretreatment to application and final curing. Our systems are engineered to reduce labor costs, minimize material waste, and deliver a superior, uniform finish on every part, every time.

Key Advantages

Continuous Automated Workflow: Eliminates bottlenecks associated with batch processing by providing a steady, uninterrupted flow of parts through loading, washing, drying, coating, curing, and unloading zones.
Maximized Vertical Space Utilization: The overhead conveyor design frees up valuable ground-level floor space for other critical manufacturing or assembly operations.
Integrated Turnkey Solutions: We engineer complete systems including spray tunnels, dry-off ovens, paint booths (powder or liquid), and curing ovens, all synchronized by a central PLC control system.
Superior Finish Consistency: Automated gun movers and precise conveyor speeds ensure uniform coating thickness and eliminate human application errors, significantly reducing rework rates.

Technical Specifications
Note: Overhead paint lines are highly customized. The specifications below represent typical parameters for a standard medium-duty industrial powder coating line configuration.

Parameter	Specification
Conveyor Type	Enclosed Track or Heavy-Duty I-Beam (X-348/X-458)
Load Capacity (Per Hanger)	50 kg - 250 kg (Customizable based on chain selection)
Design Line Speed	Variable, typically 0.5 to 3.0 meters per minute
Pretreatment System	Stainless Steel Multi-Stage Spray Washer (e.g., 3-Stage Iron Phosphate)
Dry-Off Oven	High-velocity convection, operating temp 120°C - 150°C
Application Booth Type	Cyclone or Cartridge-batch powder booth with recovery system
Application Equipment	Automatic reciprocating electrostatic guns + Manual touch-up stations
Curing Oven	Gas-fired convection or Infrared tunnel, operating temp 180°C - 220°C
Control System	Centralized HMI Touchscreen with PLC integration for all zones
Power Supply	380V-480V / 50-60Hz / 3 Phase (Region specific)

Automated Overhead Paint Line | High-Volume Industrial Finishing System 0
