High-Temperature Thermosetting Powder Curing Oven (180°C - 200°C)

MOQ:	1
Price:	USD8000-USD1200/SET
Standard Packaging:	With regular Film and Carton
Delivery Period:	15 DAYS After Deposit
Payment Method:	T/T
Supply Capacity:	30SET/MONTH

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

CoatTech

Certification

Model Number

Air Conditioner Component Powder Coating Line

Main Door::

Fold Style Or Electric Rolling Style

Coating:

10-50um

Using Energy::

Diesel,gas,steam,electric Or Other Option

Noise Level:

≤80dB

Power Supply::

380V/50HZ/3Ph Or Other Option

Material:

Steel

Energy Sources::

Water, Electricity,gas

Application::

Bus/truck Or Other Metallic Products

Heating System:

Riello Brand Burner

Product Description

Hey Guys,Let us continue break this project into 4 sub project here,here is final sub project current

Project Complete Air Conditioner Component Immersion Pretreatment & Powder Coating Production Line

Document Reference: CTI-EXP-2026-ACPC

Date: August 30,2026

Heavy-duty 108kW electric curing furnace featuring 120mm high-density rock wool insulation and dual-wing doors.

Delivers uniform cross-linking for thermosetting powders on heavy 300kg steel structures.

High-Temperature Thermosetting Powder Curing Oven (180°C - 200°C)

Project 4

3.6 Electrical Control Cabinets

Parameters	Specifications
Cabinet Allocation	Total 2 Control Cabinets: Cabinet 1 for Water Drying Oven & Spray Booth/Recovery; Cabinet 2 for Powder Curing Oven
Core Electrical Components	Chint Electric premium low-voltage breakers, contactors, thermal relays, and digital temperature controllers
Control Functions	Automatic temp regulation with digital display, delayed shutdown for circulation fans, audible/visual alarms before startup/shutdown, phase loss, overload & short-circuit protection
Wiring & Cabling	Jiangyang Cable (National Standard); Sensor cables use 3-wire shielded cables to resist Electromagnetic Interference (EMC)

4. Division of Responsibilities (Scope Matrix)

To ensure clear project execution during overseas installation, tasks are divided between Buyer (Party A) and Seller (Party B) as follows:

Category	Specific Task / Item	Responsible Party
Electrical Works	Main power supply routing from factory substation to equipment control cabinets	Buyer (Party A)
Electrical Works	Wiring from control cabinets to individual motors, heaters, and sensors	Seller (Party B)
Civil & Plant Structure	Plant lighting, fire protection systems, general plant ventilation/exhaust ducts	Buyer (Party A)
Civil & Plant Structure	Roof openings, waterproofing/leak sealing, wastewater/exhaust treatment facilities	Buyer (Party A)
Civil & Plant Structure	Civil foundation, reinforced concrete floor, trenching, and drainage channels	Buyer (Party A)
Utilities Piping	Water/Compressed air supply piping up to equipment connection points	Buyer (Party A)
Utilities Piping	Piping, valves, and pneumatic lines from equipment connection points to internal actuators	Seller (Party B)
On-site Installation	Equipment unloading, provision of forklift, crane, installation electricity and power	Buyer (Party A)
On-site Installation	Physical positioning, mechanical assembly, electrical wiring, and system commissioning	Seller (Party B)
Logistics & Living	Accommodations, meals, and local transport for Seller's installation engineers	Buyer (Party A)

5. Commercial Quotation Summary

Pricing Terms: All figures listed below represent FOB China Port net equipment price in USD (USD/RMB exchange rate = 6.7, including a coefficient factor of 1.3). Overseas freight, international shipping, local taxes, custom duties, and installation labor fees are excluded unless explicitly itemized.

No.	Equipment Module Description	Specification Summary	Qty	Price (USD)
1	Immersion Pretreatment System	4 Tanks (L4.5m × W2.0m × H3.5m), 3.0mm SUS Stainless inner, 100mm tubing outer	1 Set	$27,164.18
2	Electric Powder Curing Oven	L4.5m × W3.09m × H4.1m, 120mm Rockwool insulation, double doors	1 Set	$2,522.39
3	Curing Oven Heating System	108 kW electric finned tubes (2kW × 54), 5.5kW high-temp circulation fan	1 Set	$2,328.36
4	Suspension Overhead Track	MY-XT-200 Heavy track (30m total), gantry structure, 24 trolley wheels	1 Set	$1,746.27
5	Powder Spray Booth & 1st Recovery	L4.5m × W2.5m × H4.1m, 50mm Rockwool panels, 7-cartridge pulse recovery	1 Set	$6,597.01
6	Secondary Powder Recovery Tower	L1.4m × W1.4m × H4.0m, 9 Nano-film cartridges, 15 kW exhaust fan, silencer box	1 Set	$6,985.07
7	Electric Water Moisture Drying Oven	L4.5m × W3.09m × H3.8m, 120mm Rockwool insulation, double doors	1 Set	$2,328.36
8	Drying Oven Heating System	84 kW electric finned tubes (2kW × 42), 5.5kW high-temp circulation fan	1 Set	$1,940.30
9	Manual Electrostatic Powder Gun	2026 Smart Dual-Digital Display Gun, SS hopper, KCI powder pump, cart	1 Set	$1,358.21
10	Centralized Control System	2 Sets Control Cabinets, Chint breakers/switches, EMC shielded sensor wires	2 Sets	$2,522.39
11	Surface Painting & Finishing	Putty filling, anti-rust primer coat, final polyurethane topcoat finish	1 Lot	$388.06
12	Factory Fabrication Labor	Factory structural fabrication, cutting, welding, and assembly labor	1 Lot	$6,208.96
TOTAL PRICE (EXW / FOB China Port, Excl. Tax & Freight):				$62,089.55 USD

6. Quality Assurance, Installation & After-Sales Service

Warranty Period: 12 months starting from the date of final operational acceptance at Buyer's site.

● Manufacturing Quality: All equipment structural panels are prefabricated in modular knock-down units to facilitate overseas sea freight shipping in standard high-cube (40HQ) containers.

● Warranty Repairs: Free repair or replacement for parts defective due to design or manufacturing faults during the warranty period. For operator-induced misoperations, replacement parts are supplied at cost.

● Technical Support & Response: Remote technical assistance provided within 2 hours of fault notification. If site dispatch is required, certified engineers will be deployed within 48 hours.

● Training Services: Includes a minimum of 3 days of hands-on training for Buyer's operators and maintenance staff covering operation, daily preventive maintenance, and basic troubleshooting.

Today,we had finished this project Proposal and Quotation.
