CoatTech IR-Equipped Rapid Repair Station With Overhead Rail Heater 3-Axis Movable Infrared Curing Rail

MOQ: 1
Price: USD1000-USD6000/SET
Standard Packaging: With regular Film and Carton
Delivery Period: 15 DAYS After Deposit
Payment Method: T/T
Supply Capacity: 30SET/MONTH
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
CoatTech
Certification
CE
Model Number
CT-Prep A4
NAME:
CT-Prep A4
Using Energy::
Diesel,gas,steam,electric Or Other Option
Main Door::
Fold Style Or Electric Rolling Style
Motor::
Chinese Brand Or Import Brand
Control Sytem::
Switch Style Or PLC Touch Screen Control
Wall::
Metal Sheld,EPS,Rock Wool Of PU For Option
Color::
White Or Other Option
Application::
Bus/truck Or Other Metallic Products
Energy Sources::
Water, Electricity,gas
Coating:
10-50um
Dimention::
As Require
Highlight:

IR-equipped rapid repair station

,

3-axis movable infrared curing rail

,

overhead rail heater repair station

Product Description

CoatTech IR-Equipped Rapid Repair Station With Overhead Rail Heater 3-Axis Movable Infrared Curing Rail



Introduction:

The CT-Prep A4 creates a fully enclosed workspace similar to a spray booth but dedicated to preparation. By replacing the side curtains with 50mm EPS metal wall panels, it provides superior noise reduction and dust containment. The front remains open with a sliding curtain for easy access. Ideally suited for shops that need to strictly isolate the "dirty" sanding zone from clean painting areas.



Technical Specification Sheet

Parameter Specification
Model CT-Prep A5
Heating System 3-Axis Movable Infrared Curing Rail
Emitters Short-Wave Ruby Red Halogen Lamps
Curing Power 3 x 3.0 kW Cassettes (Adjustable)
Dimensions 6900 (L) x 3900 (W) x 2700 (H) mm
Basement Full Grating Floor (Maximum Cleanliness)
Airflow 18,000 m³/h
Safety Features Distance Sensor, Overheat Protection
Rear Wall Rockwool Insulated (Fireproof)
Application Smart Repair, Spot Priming, Putty Drying

CoatTech IR-Equipped Rapid Repair Station With Overhead Rail Heater 3-Axis Movable Infrared Curing Rail 0CoatTech IR-Equipped Rapid Repair Station With Overhead Rail Heater 3-Axis Movable Infrared Curing Rail 1CoatTech IR-Equipped Rapid Repair Station With Overhead Rail Heater 3-Axis Movable Infrared Curing Rail 2CoatTech IR-Equipped Rapid Repair Station With Overhead Rail Heater 3-Axis Movable Infrared Curing Rail 3CoatTech IR-Equipped Rapid Repair Station With Overhead Rail Heater 3-Axis Movable Infrared Curing Rail 4CoatTech IR-Equipped Rapid Repair Station With Overhead Rail Heater 3-Axis Movable Infrared Curing Rail 5

PVC Curtain Enclosure Unlike a fixed booth, the Prep Station uses sliding PVC curtains.

  • Convenience: Easily slide curtains open to move cars in and out quickly.

  • Visibility: Transparent windows allow the manager to monitor work progress.

  • Durability: Resistant to solvents and wear.

Energy Saving Strategy Don't turn on your 15kW Paint Booth just to spray a bumper with primer. Use the Prep Station (5.5kW) instead. It creates a cleaner environment than the open shop floor but costs a fraction of the price to operate.






FAQ


Q: Can I spray the final topcoat (Color/Clear) in this Prep Station? A: Technically yes, but we do not recommend it for high-quality finishes. The Prep Station is not a sealed environment like a Spray Booth, so there is a higher risk of dust. It is best used for Primer and Putty.

Q: Does it need a metal base (basement)? A: No. The most popular model is the "Rear Draft" version. It sits on your existing flat concrete floor and sucks air out through a filter box on the back wall. This saves money on ramps and steel bases.

Q: Can you make a station for 3 cars at once? A: Yes, we can connect multiple units together (side-by-side) to create a multi-bay sanding line.

Q: Is the fan unit noisy? A: We use a dynamic balanced centrifugal fan with a belt drive, which keeps noise levels below 75dB.

CoatTech IR-Equipped Rapid Repair Station With Overhead Rail Heater 3-Axis Movable Infrared Curing Rail 6
CoatTech IR-Equipped Rapid Repair Station With Overhead Rail Heater 3-Axis Movable Infrared Curing Rail 7
CoatTech IR-Equipped Rapid Repair Station With Overhead Rail Heater 3-Axis Movable Infrared Curing Rail 8
CoatTech IR-Equipped Rapid Repair Station With Overhead Rail Heater 3-Axis Movable Infrared Curing Rail 9
CoatTech IR-Equipped Rapid Repair Station With Overhead Rail Heater 3-Axis Movable Infrared Curing Rail 10
CoatTech IR-Equipped Rapid Repair Station With Overhead Rail Heater 3-Axis Movable Infrared Curing Rail 11
If you have any doubt or idea,please send the inquiry,we will respond to you immediately!



Tags:

bus pre station,

customizable paint prep station,

truck pre station
