CT-AutoMotion Robotic Precision Spray Booth With Advanced Airflow Dynamics

Designed for high-throughput automotive manufacturing and refinishing, the CT-AutoMotion integrates seamless robotic application with advanced airflow dynamics. This system ensures 100% consistent coverage, minimizes paint waste, and provides a dust-free environment essential for Class-A surface finishes on vehicle bodies.

Technical Specifications:

Feature	Specification
Application Type	6-Axis Robotic Spray Arms (Dual Setup)
Airflow Style	Full Down-Draft (0.3 - 0.5 m/s)
Filtration Level	99% efficiency (Ceiling & Floor filters)
Control System	HMI Touchscreen with PLC Integration
Lighting	> 1000 Lux LED (Explosion Proof)
Heating System	Direct Fired Gas Burner or Electric IR

I. System Positioning
Replaces manual coating operations, enabling fully unmanned surface treatment-spraying-curing-inspection processes. Delivers high-precision, efficient, and eco-friendly surface solutions for automotive, appliance, and machinery manufacturing.

II. Core Process Flow

Stage	Function	Key Technologies
1. Loading & Pre-treatment	Automated part identification, dust/static removal	RFID tracking · Ionized air cleaning
2. Pre-treatment	Degreasing/Phosphating/Rinsing/Drying (enhance adhesion)	Closed-loop chemical control · Tunnel spray/immersion
3. Automated Spraying	Robotic precision coating (primer/color/clear)	6-axis robots · Electrostatic rotary bell (30%+ paint savings) · Smart color change (≤10 sec)
4. Flash-off	Solvent evaporation (prevent blistering)	±1°C temp/humidity control
5. Curing	High-temperature film curing (80-180°C)	Multi-zone IR/convection ovens · Waste heat recovery (20%+ energy saving)
6. Cooling & QC	Forced cooling · AI defect inspection	Machine vision (runs/sags/color deviation) · Laser thickness gauge

III. Smart Core Technology

Dynamic parameter optimization: Real-time adjustment of spray pressure/flow (responsive to ambient temp/humidity)

IV. Key Performance Advantages

Indicator	Traditional Line	Automated Line
Coating Uniformity	>15% human error	<3% robotic accuracy
VOC Emissions	Non-compliant	99% RTO purification
Total Cost	40%+ labor cost	3-year ROI (paint/labor savings)
Daily Output	Limited by shifts	24/7 continuous production

V. Industry Applications

Heavy Machinery: Anti-corrosion coating for excavators/cranes (1000h+ salt spray test)
Consumer Electronics: UV coating for smartphone casings (cleanroom-grade)
Furniture: Distressed wood effects (multi-texture program library)

VI. Implementation Requirements

Space: Linear layout ≥80m (or U-shaped compact design)
Energy: ≥500kW power + natural gas supply (curing ovens)
Maintenance: IoT remote diagnostics + robotic arm calibration

VII. Industry Trends

Greener Processes: Waterborne/powder coating retrofits
Modular Design: Scalable line segments for capacity needs

Key Translation Notes:

Terminology Alignment
- Flash-off (SAE J1545 standard)
- Phosphating (ASTM B201 process)
- Electrostatic Rotary Bell (Gema equipment terminology)
Technical Conventions
- Temperature ranges use 80-180°C (not "℃")
- Measurements: ±1°C (not "±1℃")
Regulatory Compliance
- VOC treatment: RTO (Regenerative Thermal Oxidizer) - EPA Method 25A
- Salt spray test: 1000h+ per ASTM B117
Industry-Specific Phrasing
- Distressed Effects (furniture industry term)
- Cleanroom-grade (SEMI F1 standard)

Tag:

Place of Origin:	CHINA
Brand Name:	Coarrech
Certification:	ISO9001、CE
Model Number:	CT-ZT-10

Minimum Order Quantity:	1pc
Price:	1000-100000 USD
Packaging Details:	With regular Film and Carton
Delivery Time:	20 DAYS After Deposit
Payment Terms:	T/T
Supply Ability:	20SET/MONTH

Application:	Metallic Products	Control Method:	LC + Touch Screen
Machine Type:	Spray Booth, Conveyor System, Curing Oven	After-Sales Service:	Online Support/ Field Installation, Commissioning And Training
Type:	Automatic Spray Painting Coating Line	Spray Painting Process:	Automated Spray Painting
Suitable For:	Automotive, Product Components, Helmets And Similar Items
Highlight:	robotic spray booth with airflow dynamics , smart painting line robotic system , precision spray booth with warranty
